Informations générales
ECTSECTS
2
Goal(s)
NOTE :
this course will be given after the course entitle "CFD code training"
Introduction to the power transmission systems using a fluid (oil) under pressure (oil hydraulics)
Description of the various components of power transmission chains
Use in (mainly) all-or-nothing circuit
Introduction to the simulation of these systems
Teamwork in the frame of workshop (BE) activities
Content(s)
1. Lecture : 12 hours
Study of the components involved in these transmission systems.
Hydraulic fluids. Volumetric machines (pumps and engines)
Jacks (linear and rotary). Accumulators. Distribution. Valves (control of pressure and flowrate). Reservoirs.
2. Workshops (BE) : 12 hours
Study of circuits. Introduction to the simulation of circuits and components.
3. case study : 4 hours of exercises (TD)
Pollution and filtration (speaker from industry)
Prerequisites :
Knowlegde of elementary technological functions : guidance in rotation...
General mechanics (kinematics, dynamics)
Fluid mechanics (head losses...)
Test
Grade obtained for the workshop (BE) report
Calendar
S1
Additional Information
26h = 12 h CM + 4 h TD + 12 h BE
Bibliography
- COMPAIN Jean - Le mécanicien en circuits oléohydrauliques - Paris : SEDOM, 1977.
- DUCOS Claude - Recueil de schémas et de problèmes d'hydraulique industrielle - 3ème édition - Paris : TECHNIQUE ET DOCUMENTATION, 1988 - 403 pages - ISBN 2 85206 437 5.
- FAYET Georges - Hydraulique, machines et composants - Paris : EYROLLES, 1991 - 289 pages.
