Number of hours
- Lectures 8.0
- Tutorials 8.0
- Laboratory works 16.0
ECTS
ECTS 2.5
Goal(s)
Deepen the knowledge on hydraulic transmissions : regulation study, proportional components, hydraulic servo-controller, hydrostatic transmissions.
Dynamic simulation of this systems behavior.
Keywords : Hydraulic Controls - Hydraulic Regulations - Feedback control Electro - Hydraulic Proportional - Hydrostatic transmissions.
Contact Jean-Luc AMENContent(s)
1 - Course:
Hydraulic generations : commands and controls, constant horse power control, pressure and combined flow/pressure (load sensing) compensator
Hydraulic actuators : dynamic characteristics.
Static and dynamic of valves and servovalves.
Hydraulic and electro-hydraulic servomechanisms.
Hydrostatic transmissions (closed circuit).
2 - Design office workshop :
Circuit conception - Simulation of these circuits and components using the software AMESim.
3 - Cast study:
One case study, animated by external speaker : simulation of hydraulic circuits and compoments using AMESIm. Complement by using the linear analysis tools.
Prerequisites
Knowledge on basic hydraulic components and associated circuits.
Test
Additional Information
Course list
Curriculum->ME->Semester 5
Bibliography
ADEPA - Le guide de la commande d'axe Technoguide E - Paris : ADEPA, 1989 - ISBN 2 950 2194 03.
BLACKBURN J.F. , REETHOF G. , SHEARER J.L. - Mécanismes et servomécanismes à fluide sous pression - Tome 1 - Paris : DUNOD, 1966 - 444 pages.
GUILLON Marcel - L'asservissement hydraulique et électrohydraulique - Tomes 1 et 2 - Paris : DUNOD, 1972 - 443 pages.
